Description
| Sensor Characteristics | |
|---|---|
| Fingerprint Sensor Type | Optical Sensor |
| Spatial Resolution | 500 DPI ± 2% |
| Platen Area | 14.0 mm x 17.0 mm |
| Image Size | 276 x 336 Pixels |
| Image Grayscale | 256 (8-Bit Gray Level) |
| Light Source | Red LED |
| Approx. Weight | 0.140 kg |
| Maximum Acquisition Time (Placement to Template) | < 2 Sec |
| Approx. Dimension (L x W x H) | 61(L) x 91(W) x 54(H) mm |
| Capture Mode | Auto capture with built-in quality check (incorporates NIST quality considerations) |
| Security | |
| Crypto Operation | Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support |
| Secure Memory | TEE support by the device, secure memory support with key wrapping feature |
| Secure Boot | Secure boot support by the device |
| Electrical | |
| Operating Voltage | 5V ± 5% (USB Powered Device) |
| Operating Current | < 90 mA |
| Standby Current | 50 mA |
| Interface | USB 2.0 |
| Environmental | |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | 0 to 50°C |
| Humidity (Operating / Storage) | < 90% RH, Non-condensing |
| Compliance to Standards | |
| Environmental, Health and Safety | RoHS |
| Safety | EN/IEC 62368-1, IS 13252 (Part 1) |
| EMI / EMC Compliance | CE, FCC Part 15B |
| Image Quality Compliance | FBI PIV, STQC |
| IP Rating | IP54 |
| Device Driver | WHQL certified |
| Operating System | Windows 10 & above OR Android 7 & above |
| Biometric Data Interchange Format | ISO 19794-2 for minutiae & ISO 19794-4 for Image Template in Encrypted PID Data Block |
