Description
| Specification | Details |
|---|---|
| Switch Capacity | 12 Gbps Full duplex |
| Uplink Ports | 2, 1000Mbps; Transmission Distance: 0-100m |
| Poe Power Budget | 48W |
| Anti-thunder Level | Common mode: 2KV; Differential mode: 2KV |
| ESD | Air discharge: 1.5KV; Contact discharge: 1.5KV |
| Ethernet Port Light | Light off: Link is disconnected Red light on: Powering but data disconnected Light flash quickly: Data Transmitting |
| Network Port | 6 |
| Transmission Distance | 0-100m/100 Mbps |
| Poe Ports | 4, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port; Transmission distance: 0-100m |
| Poe Power Supply | 1/2(+), 3/6(-) |
| Poe Standard | IEEE802.3af, IEEE802.3at |
| Packet Forwarding Rate | 1.488Mpps/port |
| MAC Address List | 2K |
| Power Source | Built-in Power Supply, Input: 110-264V AC, 50/60Hz |
| Power Consumption | <5W |
| Operating Temperature | -10°C~ -50°C |
| Humidity | 10%-95%, non-condensing |
| Storage Temperature | -40°C~70°C |
| Dimension | 202mm x 140mm x 45mm (L x W x H) |
