Description

Description

Specification Camera Image Sensor 2 MP CMOS Signal System PAL/NTSC Resolution 1920 (H) ? 1080 (V) Frame Rate TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC Min. Illumination 0.01 Lux @ (F1.6, AGC ON), 0 Lux with white light Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s Lens 2.8 mm/3.6 mm fixed lens Field of View 2.8 mm, horizontal FOV: 102?, vertical FOV: 55?, diagonal FOV: 122? 3.6 mm, horizontal FOV: 84?, vertical FOV: 44?, diagonal FOV: 99? Lens Mount M12 Day & Night 24/7 Color Imaging WDR (Wide Dynamic Range) Digital WDR Angle Adjustment Pan: 0? to 360?, Tilt: 0? to 180?, Rotation: 0? to 360? Image White Light Auto/Off Image Mode STD/HIGH-SAT AGC Yes Day/Night Mode Color White Balance Auto/Manual AE (Auto Exposure) Mode DWDR,BLC,HLC,Global Noise Reduction 2D DNR Language English Function Brightness, Contrast, Mirror, Sharpness, Smart Light, Saturation Interface Video Output Switchable TVI/AHD/CVI/CVBS Power Output 12 VDC General Operating Conditions -40?C to 45?C (-40?F to 113?F), Humidity: 90% or less (non-condensing) Power Supply 12 VDC?25% *You are recommended to use one power adapter to supply the power for one camera. Consumption Max. 2.3 W Material Plastic White Light Range Up to 20 m Approval Protection IP66
